Int J Biol Sci 2009; 5(7):659-666. doi:10.7150/ijbs.5.659
Karyology of eight species of bats (Mammalia: Chiroptera) from Hainan Island, China
1. College of Life Science, Guangzhou University, Guangzhou 510006, China.
This is an open access article distributed under the terms of the Creative Commons Attribution (CC BY-NC) License. See http://ivyspring.com/terms for full terms and conditions.
How to cite this article:
Wu Y, Motokawa M, Li YC, Harada M, Chen Z, Lin LK. Karyology of eight species of bats (Mammalia: Chiroptera) from Hainan Island, China. Int J Biol Sci 2009; 5(7):659-666. doi:10.7150/ijbs.5.659. Available from http://www.ijbs.com/v05p0659.htm
Karyotypes and chromosomal data are presented for eight bat species representing two families (Rhinolophidae and Vespertilionidae) from Hainan Island, China. The species investigated were Rhinolophus lepidus (2n = 62, FN = 60), R. pusillus (2n = 62, FN = 60), R. affinis (2n = 62, FN = 60), R. sinicus (2n = 36, FN = 60), Myotis horsfieldi (2n = 44, FN = 52), Pipistrellus abramus (2n = 26, FN = 44), Miniopterus australis (2n = 46, FN = 50) and M. schreibersii (2n = 46, FN = 50). The karyotype of Rhinolophus lepidus is reported for the first time.
Keywords: Karyology, bats, Rhinolophidae, Vespertilionidae, chromosome, Hainan Island.
Hainan Island is separated from the mainland of southern China by the narrow Strait of Hainan, which 17 to 20 km wide. It is the second largest island in China, with a land area of 34,000 km2, and the most southern province in China. The surface of Hainan Island is diversified geomorphologically, rising in the interior to mountains with altitudes exceeding 1,400 m near Wuzhishan and Jianfengling, which protect the southern part of the island from the monsoons. Hence, this region is quite different from the adjacent mainland of southern China climatically. The island's vegetation types include lowland shrubs, lowland evergreen forest, semi-evergreen forest, tropical rain forest, and montane evergreen forest. It has the best protected and largest area of primary tropical rain forest in China.
The fauna of Hainan Island comprises about 112 species of mammal, including 27 species of bat belonging to seven families. In a survey of bats, three species were only recently recorded from Hainan Island [1-4]. Although all 27 bat species are considered to be conspecific with populations in southern China, subspecific status has been proposed for the Hainan populations of many taxa. Comparative studies of the populations in southern China and Hainan Island are needed to evaluate their degree of differentiation and to clarify their taxonomic status based on morphological and genetic perspectives. Conventional karyotyping is an important taxonomic tool for assessing the diversification between species, subspecies, and populations. Although 52 bat species in China have been karyotyped so far [5-17], no information is available for the bats of Hainan Island. This study reports the conventional karyotypes of eight species of bat representing two families (Rhinolophidae and Vespertilionidae) collected from Hainan Island as well as G- and C-banding karyotypes for selected species, and discusses their karyological relationships with conspecific populations and congeneric species in southern China and adjoining regions.
2. Materials and Methods
Twenty-eight specimens of eight species of bats were captured on Hainan Island, China in February 2005 and September 2008 (Table 1). The identification of these bats was based on standard taxonomic papers [18-21]. Voucher specimens are deposited in the College of Life Science, Guangzhou University, Guangzhou. Chromosome preparations were made from primary culture cells of lung and tail tissue using the methods of Harada and Yosida . G- and C-banding differential stainings were applied for selected species following the methods of Seabright  and Sumner , respectively. The nomenclature of chromosomes follows Levan et al. . The diploid number (2n) was determined by observing 30 metaphase cells in each specimen, and the fundamental number (FN) was defined as the total number of autosomal arms (Table 2).
Species, numbers, and localities of bat specimens collected from Hainan Island, China examined in this study.
Karyotype data for the eight bat species collected from Hainan Island, China.
3. Results and Discussion
Karyotypes of four species in the genus Rhinolophus
This is the first karyotype description for Rhinolophus lepidus, which is widely distributed in Asia from Afghanistan to China, as well as in Sumatra . The karyotype of R. lepidus from Hainan Island was 2n = 62 and FN = 60 (Fig. 1), consisting of 30 medium-sized to small acrocentric autosomal pairs, a large subtelocentric X chromosome, and a small acrocentric Y chromosome. Secondary constrictions were detected adjacent to one pair of medium-sized acrocentric chromosomes.
The karyotypes of R. pusillus and R. affinis from Hainan Island were also 2n = 62, FN = 60 (Fig. 2A, B), consisting of 30 medium-sized to small acrocentric autosomal pairs, a large subtelocentric X chromosome, and a small acrocentric Y chromosome. A secondary constriction was detected in one pair of medium-sized acrocentric chromosomes in both species. Rhinolophus pusillus and R. affinis are widely distributed in the Indomalayan region and China and each contains nine subspecies . The two subspecies from Hainan (R. pusillus parcus and R. affinis hainanus) examined in this study showed no karyological differences from previous reports for the following taxa: R. p. szechwanus from the Chinese provinces of Sichuan  and Guizhou  (reported as R. cornutus); R. p. calidus from the Chinese provinces of Anhui  (as R. cornutus pumilus) and Guangdong  (as R. cornutus); R. p. lakkhanae from Thailand ; R. a. himalayanus from the Chinese provinces of Guizhou  and Henan ; R. a. macrurus from the Chinese provinces of Anhui  and Guangdong  (as R. affinis); and R. a. macrurus from Thailand .
The reported comparative karyological data for 35 Rhinolophus species in the world [6, 15, 27-31] suggest that the karyotype 2n = 62, FN = 60 is likely the conserved among the species and subspecies of the genus Rhinolophus and is shared by R. lepidus, R. pusillus, R. affinis, R. macrotis, R. rex, and R. huananus (reported as R. macrotis ). Karyotype of R. lepidus is also considered a member of this 2n = 62, FN = 60 karyotype without recognized difference in G-banding pattern compared with Mao et al. . This 2n = 62, FN = 60 karyotype was thought to be ancestral state of the genus Rhinolophus, but recent karyotype study suggested that 2n=58 karyotype is more closely related to ancestral karyotype of the genus .
The karyotype of R. sinicus was 2n = 36, FN = 60 (Fig. 3), consisting of 13 large-to-small metacentric or submetacentric pairs and four medium-sized to small acrocentric pairs of autosomes, a medium-sized subtelocentric X chromosome, and a small subtelocentric Y chromosome. This species had a prominent secondary constriction involving one pair of medium-sized acrocentric chromosomes. The karyotype of R. sinicus from Hainan Island (2n = 36, FN = 60) does not differ from conspecific populations in the Chinese provinces of Anhui  (reported as R. rouxii sinicus), Sichuan , and Guangdong  in conventional karyotype and that from "south-western China" also in G-banding pattern , but does differ from the 2n = 56, FN = 60 karyotype of R. rouxii reported from India and Sri Lanka . These karyological differences between R. sinicus and R. rouxii support the view that these two taxonomically confused taxa both represent distinct species, as previously proposed [14, 15, 26].
Conventional (A), G-banding (B), and C-banding karyotypes of Rhinolophus lepidus from Hainan Island, China. Secondary constrictions are indicated by arrows.(Click on the image to enlarge.)
Conventional karyotypes of R. pusillus (A) and R. affinis (B) from Hainan Island, China. Secondary constrictions are indicated by arrows.(Click on the image to enlarge.)
Conventional (A), G-banding (B), and C-banding karyotypes of Rhinolophus sinicus from Hainan Island, China. Secondary constrictions are indicated by arrows.(Click on the image to enlarge.)
The karyotype of Myotis horsfieldi
The karyotype of Myotis horsfieldi was 2n = 44, FN = 50, consisting of three large and one small metacentric or submetacentric pairs and 17 medium-sized to small acrocentric pairs in autosomes, a medium-sized submetacentric X chromosome, and a small acrocentric Y chromosome (Fig. 4A). The karyotype of Myotis horsfieldi from Hainan Island does not differ from conspecific population in Borneo . The vespertilionid genus Myotis is one of the most diverse mammalian genera and includes 103 species , but it is also one of the most karyologically conservative genera. A diploid number 2n = 44 characterizes all 47 species for which karyotypes have been reported [22, 33]. Chromosomal variation is essentially restricted to the presence of heterochromatic short arms on the smaller autosomes, variation in the location of active nucleolus organizer regions (NORs), as well as differences in the size of the Y chromosome [22, 33, 34]. In addition, an inverted autosome and a duplicated translocation involving the X chromosome have been reported in M. pruinosus . An extra pair of acrocentric autosomes (2n = 46) has also been reported in M. annectans from Thailand  and in M. davidii from Guangdong . The karyotype of M. horsfieldi in this study is the conservative one and showed no additional translocation.
The karyotype of Pipistrellus abramus
The karyotype of Pipistrellus abramus from Hainan Island was 2n = 26, FN = 44 (Fig. 5), consisting of ten large to medium-sized metacentric or submetacentric pairs and two small acrocentric pairs in autosomes, a medium-sized acrocentric X chromosome, and the smallest acrocentric Y chromosome. The conventionally stained karyotype of P. abramus from Hainan Island does not differ from conspecific populations from the Chinese provinces of Zhejiang, Henan, and Sichuan, Taiwan, Japan, or Korea [8, 14, 37-43]. Large negative G-band and positive C-band areas were found in the pericentromeric regions of chromosome 1 through 4, 10, 11 and X; and these are considered centromeric constitutive heterochromatin. This characteristic was also reported from Japan and Taiwan [38, 41, 42], and any difference in G- and C-banding patterns among populations from Hainan Island, Japan and Taiwan was detected.
Karyotypes of Myotis horsfieldi (A), Miniopterus australis (B), and M. schreibersii (C). Secondary constrictions are indicated by arrows.(Click on the image to enlarge.)
Conventional (A), G-banding (B), and C-banding karyotypes of Pipistrellus abramus from Hainan Island, China.(Click on the image to enlarge.)
The karyotype of two species in the genus Miniopterus
The karyotypes of Miniopterus australis and M. schreibersii from Hainan Island were both 2n = 46, FN = 50 (Fig. 4B, C), both consisting of two large and one small metacentric or submetacentric pairs and 19 medium-sized to small acrocentric pairs in autosomes, a submetacentric X chromosome, and an acrocentric Y chromosome. One small acrocentric pair (No. 20) had a secondary constriction adjacent to the centromere. The karyotype of M. australis from Hainan Island is very similar to a previous report for the same species from Borneo . The karyotype of M. schreibersii from Hainan Island is similar to those for M. schreibersii from Borneo and Taiwan [9, 32], M. s. chinensis from Anhui Province, China , M. s. pallidus from Russia , and M. s. fuliginosus from Japan [40, 46] and Guizhou Province, China  (as M. fuliginosus). The members of this genus have likely retained the karyologically conservative state.
Diversification of bats from Hainan Island
Eight species of bats from Hainan Island examined in this study did not show any karyological differences from the conspecific populations or congeneric species from southern China and adjoining regions. Because karyological analyses suggest no evidences for differentiation, we follow the current taxonomic status to consider the Hainan bats as conspecific with the populations in southern China and adjoining regions. The karyological characteristics, however, are very conservative in some genera as discussed above. Morphological and genetic studies are also desired for more precise evaluation of the diversification and the taxonomic status of bats in Hainan Island.
We acknowledge grants from the National Natural Science Foundation of China (NSFC, No. 30370167, 30499341, and 30670277) and the National Study Abroad Foundation of China (No. 21844046), and a NSFC-JSPS Joint Research Project Grant (No. 30811140092). We thank CD Wang, ZL Jiang, WH Yu, L Guo, and W Lei for their kind help with the field work on Hainan Island, China.
Conflict of Interest
The authors have declared that no conflict of interest exists.
